| 机型 Type | ZDJ280 | ZDJ500 |
| 纸料宽度 Paper Roll Width | 400-760mm | 620-1020mm |
| 纸筒长度 Tube Length | 190-370mm | 300-1000mm |
| 纸袋面宽 Bag Body With | 120-280mm | 300-500mm |
| 袋底宽 Bottom Size | 60-150mm | 150-220mm |
| 原纸重 Paper Thickness | 60-160g/m2 | 35-160g/m2 |
| 放卷**直径 Max.Paper Roll Diameter | φ1200mm | φ1200mm |
| 基材卷芯内径 Material Core Diameter | φ76mm | φ76mm |
| **制袋速度 Max.Production Speed | 150bags/min | 120bags/min |
| 机器总功率 Total Power | 3.5kw | 7.5kw |
| 机器重量 Weight of Machine | approx.3000kg | approx.5000kg |
| 外形尺寸 Overall Dimension(L*W*H) | L7000mm*W1600mm*H1600mm |
