主要技术参数Technical Data
机型 Type | ZDJ500 |
纸料宽度 Paper Roll Width | 620-1020mm |
纸筒长度 Tube Length | 300-1000mm |
纸袋面宽 Bag Body With | 300-500mm |
袋底宽 Bottom Size | 150-220mm |
原纸重 Paper Thickness | 35-160g/m² |
放卷**直径 Max.Paper Roll Diameter | φ1200mm |
基材卷芯内径 Material Core Diameter | φ76mm |
**制袋速度 Max.Production Speed | 120bags/min |
机器总功率 Total Power | 7.5kw |
机器重量 Weight of Machine | approx.5000kg |
外形尺寸 Overall Dimension(L*W*H) | L7000mm*W1600mm*H1600mm |
产品介绍Product introduction
新型无风琴方底纸袋机，由于纸袋的底部是六角形的又称六角方底纸袋机。这款机器是业界首台成功面市的六角底纸袋机，技术性能处于行业**水平。经过客户的使用验证，机器性能稳定可靠，速度快捷，现正式投入市场销售。那么，它与平常的方底纸袋机有什么不同呢？有两个方面：一、纸袋无风琴，即没有传统的M边侧边。二、纸袋的底部是六边形的，而一般的方底纸袋底部是四边形（长方形）的。
The square bottom paper bag machine of WU FENG QIN, has hexagonal side at the bottom. This machine is the industrys first six corner square bottom paper bag machine, and the technical performance is in the lead in the industry. The machine’s operation is stable, and the machine has high speed. Now the machine is put into the market sales. The machine can produce paper bag without a traditional M side and broadside. And the bottom of the bag is hexagonal.
